Survey first: $300–$750
A recorded camera run with distances marked. Yours to keep, and usually credited if the work goes ahead.
CCTV Surveyed, Then Relined
No-Dig Drain
Repairs In
Double Bay
A cracked or root-damaged drain does not have to mean a trench through the garden. A resin liner is cured inside the existing pipe from an access point you already have, sealing every joint along the run, and the surface above is never touched.
- Licence 368473C, fully insured
- CCTV survey before any quote
- Nothing dug up, nothing reinstated
When A Liner Is The Right Repair In Double Bay
A resin-saturated liner is drawn into the existing pipe through an access point, inflated so it presses against the wall, and cured until it hardens. What you are left with is a continuous pipe inside the old one, with no joints along its length and a slightly smaller bore than the original.
Nothing is excavated, and the cured surface is smoother than the clay or concrete it lines, so flow is typically maintained or improved despite the small loss of diameter. On a property where a driveway, mature garden or paving sits over the line, that is the whole argument.
The stain that appears two floors down
Water tracks along beams and slab falls, so the lot reporting the damage is often nowhere near the lot with the fault. Opening ceilings on a guess is how a small repair becomes three angry owners.
Camera and non-destructive location come first for exactly that reason. Once the defect is located and measured from a known point, the repair is a defined job and the liner goes in without exploratory demolition.
Shared lines, landlords and who authorises the work
In a strip of tenancies the drainage is frequently shared, which means the fault is often not under the premises reporting it, and the party who pays is not always the party who called.
That is worth settling before the quote rather than after. Camera footage with distances marked from a known access point is what makes the conversation with a landlord or a neighbouring tenant short, because it shows exactly where the defect sits.
Digging near the water is the expensive option
Excavation close to the foreshore brings problems that have nothing to do with plumbing: unstable saturated ground, dewatering, restricted access down a narrow lot, and reinstatement of landscaping that was not cheap to build.
The trenchless comparison is not repair against repair. It is repair against repair plus everything sitting on top, and on a waterfront block that second half is usually the bigger number.
Steep blocks are where no-dig earns its money
Streets sloping down to the bay move stormwater fast, and blocked pits back up in heavy rain. We clear them quickly to stop flooding.
Excavating on a slope is a different job from excavating on the flat. Access for a machine is often impossible, the spoil has to go somewhere, trench walls need support, and reinstating a tiered garden or a retaining structure can cost more than the drainage work it was dug for.
Relining sidesteps all of it. The line is repaired from an existing access point, and the surface above stays exactly as it is. On a difficult block the saving is not marginal, it is often the difference between doing the job and deferring it.
Stormwater lines are relinable too
Most people associate relining with sewers, but stormwater suffers the same failures and reline just as well: cracked lengths, open joints, roots, and sections that have silted because the fall has flattened. On a property that floods in every serious downpour, the line is often the reason rather than the rain.
The camera run matters more here than anywhere. Clearing a surcharging pit at the height of a storm tells you almost nothing; the same line inspected on a dry day tells you whether you have a blockage or a defect.
What it costs in Double Bay
Liner, $500–$900 a metre
The prevailing 2026 Sydney range for residential sewer relining.
Single defect patch, $1,500–$4,000
Proportionate for one fault in a sound run. We will recommend it over a full liner when that is what the camera shows.
Full-length reline, $6,000–$15,000
For a run failing along its length, which on old clay is the common finding.
The dig-up alternative, from $2,500 upward
Plus reinstatement. On a bare lawn it can win. Under anything you would miss, it usually does not.
Indicative Sydney ranges for 2026. Your job is quoted in writing after the camera survey. Figures here are indicative of the 2026 Sydney market rather than a quote from us, you get your own number as a fixed price before any work starts.
What Actually Happens
Step 01
Step 01
Camera The Line
A CCTV survey establishes the material, the diameter, where the defects are and how far they sit from the access. You see the footage, and it is what the quote is built from.
Step 02
Agree The Method
Patch or full length, and occasionally excavation instead. We will tell you when digging is the better answer even though it is the bigger quote.
Step 03
Clean, Line And Cure
The run is jetted so the liner bonds to pipe rather than debris, the liner is installed through the existing access, and it cures in place. Most domestic jobs are a single day.
Step 04
Reinstate And Re-Camera
Every branch the liner passed is reopened from inside, then the run is cameraed again so you can see it is continuous and the junctions are clear.
Want The Camera Run First?
Send it through and we will come back with what it is likely to be, what the survey costs, and whether relining is even the right conversation.
Relining, Answered Properly
Cost, lifespan, method, and the cases where a liner is the wrong answer.
No. A liner takes the shape of the pipe it cures inside, so it cannot correct a run that has sagged into a belly or lost its fall, and it has nothing to line against where a section has collapsed. Badly deformed or crushed pipe needs replacing. What relines well is the common case: a sound barrel with cracked or open joints, which is most older clay drainage.
Most domestic relining is a single day on site: set up at an existing access point, jet and camera the line clean so the liner bonds to pipe rather than debris, install, cure, then reinstate the junctions and camera it again. Water is off for part of the day. Larger or commercial runs are staged, and are often scheduled overnight or across one closed day so the premises can trade.
Cured-in-place liners are generally rated at around fifty years, comparable to a new pipe and usually longer than the remaining life of the earthenware they are installed into. The reason the figure is that high is structural rather than promotional: a liner has no joints along its length, and joints are what fail. Most warranties on the workmanship run considerably shorter than the rated life of the material, so ask what you are actually being given.
Only the affected line, and usually only for part of a day. What needs planning is the notice: most buildings require it before a riser is isolated, so the schedule matters as much as the method. Turning up and shutting water off to a line of lots unannounced is how a straightforward repair becomes a building-wide complaint.
In a strip of tenancies the drainage is often shared, so the fault is frequently not under the premises reporting it. Settle it before the quote rather than after. Camera footage with distances marked from a known access point is what makes the conversation with a landlord or neighbouring tenant short, because it shows exactly where the defect sits.
Only if the cause is a defect rather than the gradient. On a steep run, waste can outrun the water carrying it and settle at the first flat section, producing a blockage at the same point regardless of the household. A liner seals the pipe but keeps its shape, so if the profile is wrong the pooling continues. The camera run distinguishes the two.
Often yes, and that surprises people. A well laid clay line of that age usually still has a sound barrel; what has gone is the mortar or rubber at each joint, and there is one every few hundred millimetres. You are sealing a long series of small openings, not replacing a pipe, and that is exactly what relining is for.
Book A Relining Survey In Double Bay
Ring us or leave your details. You will get a time for the inspection, not a price invented over the phone.
